3~5Gallon Bottle Automatic Washing/Filling/Capping Machine

Products Mode: D1.5

1:Filling medium: Water
2:Combined type automatic machine (3-in-1)
3:Capacity: 100~1200 bottle/hour based on 5gallon bottle
4:PLC + Touch Screen control, various protect/measure device;
5:Main material: Stainless steel 304/316
6:Bottle type: 3~5Gallon, PET/PE bottle

Description

QGF is a kind of professional filling machine integrates washer, filler & capper together for 3~5gallon bottle. It’s made by stainless steel material, resisting corrosion and easy to clean. The electric components and air circuit elements are all of international famous brand. The washing process use multi-washing liquid spray and thimerosal spray. This thimerosal can be used circularly, the capping process can cap bottle automatically, this line equips with water spraying device in order to ensure those caps sterilizer and clean, it also can automatically feed bottle, washing, sterilizing, filling, capping and product bottle discharging, with complete function, modem design and high degree of automation, it’s a new kind of bottled water auto-production line, which integrates mechanism, electricity and pneumatics technologies together.

Function:

1.It’s specially used for filling 3~5 gallon bottled water;
2.It can suitable for different shape bottle;
3.The machine is designed for bottles such as PVC, PE, PET, etc.
4.The machine line with stainless steel washing nozzles, pressure filling vales, screw capper, hot steam film shrinkage machine top quality line;
5.Filling time is controlled by PLC with touch screen;
6.The machine adopts high quality stainless steel 304/316;
7.The machine design appreance is nice, easy operation, maintenance, running stable, etc.

Pecification:

Model	QGF100	QGF200	QGF300	QGF450	QGF600	QGF900	QGF1200
Filling heads	1	2	3	4	4	6	8
ottle volume	18.9Liter (5Gallon)
ottle size	Φ270×490 mm
Capacity	100	240	350	450	600	900	1200
Air pressure	0.4~0.6MPa				0.6MPa
Air consumption	0.37m³/min	0.6m³/min	0.8m³/min	1m³/min	1.5m³/min	1.8m³/min
Motor power	1.38kw	1.75kw	3.8kw	3.8kw	7.5kw	9.75kw	13.5kw
Weight	680kg	800kg	1500kg	2100kg	3000kg	3500kg	4500kg

Working process:

Step-1: Empty bottle loading;
Step-2: Washing by hot alkali water (heating by electric heating tube)
Step-3: Washing by hot alkali water (heating by electric heating tube)
Step-4: Drop drain
Step-5: Washing by disinfect water
Step-6: Washing by disinfect water
Step-7: Drop drain
Step-8: Washing by recycle water
Step-9: Washing by recycle water Step-10: Drop drain
Step-11: Washing by pure ozone water
Step-12: Washing by pure ozone water
Step-13: Drop drain
Step-14: Bottle overturn
Step-15: Bottle filling
Step-16: Bottle capping
Step-17: Product bottle output
